INJECTION UNIT

A

B

C

Screw diameter

mm

40

45

48

Screw L/D ratio

L/D

22.5

20

18.8

Shotvolume(theoretical)

cm3

253

320

364

Injection weight(ps)

g

230

291

331

Injection rate

g/s

108

128

158

Plasticizing capacity

g/s

15.8

20

24.7

Injection pressure

Mpa

202

159

140

Screw speed

rpm

0-185

CLAMPING UNIT

Clamping force

kN

1680

Open stroke

mm

430

Spacebetweentiebars(w*h)

mm

470*470

Max.Mould height

mm

500

Min.Mould height

mm

180

Ejector stroke

mm

130

Ejector tonnage

kN

45

Ejector force

N

5

OTHERS

Max.Pump pressure

Mpa

16

Pump motor power

kW

15

Heating power

kW

7.5

Machine dimension(l*w*h)

Mpa

5.1*1.4*1.9

Machine weight

t

5

Oil tank capacity

L

240

Shot stroke

mm

310
