Specifications

INJECTION UNIT

 A

 B

 C

Screw diameter

mm

35

38

40

Screw L/D ratio

L/D

23.9

22

20.9

Shotvolume(theoretical)

cm3

154

181

201

Injection weight(ps)

g

141

165

183

Injection rate

g/s

80

95

105

Plasticizing capacity

g/s

12

13

15.3

Injection pressure

Mpa

219

186

167

Screw speed

rpm

0-220

CLAMPING UNIT

Clamping force

kN

1800

Open stroke

mm

340

Spacebetweentiebars(w*h)

mm

370*370

Max.Mould height

mm

400

Min.Mould height

mm

150

Ejector stroke

mm

100

Ejector tonnage

kN

33

Ejector force

N

5

OTHERS

Max.Pump pressure

Mpa

16

Pump motor power

kW

11

Heating power

kW

6.5

Machine dimension(l*w*h)

Mpa

4.2*1.25*1.8

Machine weight

t

3.3

Oil tank capacity

L

210

Shot stroke

mm

250
