Specifications

INJECTION UNIT

 A

 B

Screw diameter

mm

32

36

Screw L/D ratio

L/D

21.5

19.8

Shotvolume(theoretical)

cm3

101

123

Injection weight(ps)

g

91.9

111

Injection rate

g/s

70

82

Plasticizing capacity

g/s

10

13

Injection pressure

Mpa

188

148.5

Screw speed

rpm

0-220

CLAMPING UNIT

Clamping force

kN

800

Open stroke

mm

275

Spacebetweentiebars(w*h)

mm

320*320

Max.Mould height

mm

320

Min.Mould height

mm

120

Ejector stroke

mm

80

Ejector tonnage

kN

27

Ejector force

N

1

OTHERS

Max.Pump pressure

Mpa

16

Pump motor power

kW

9

Heating power

kW

5.3

Machine dimension(l*w*h)

Mpa

3.5*1.2*1.6

Machine weight

t

2.7

Oil tank capacity

L

210

Shot stroke

mm

180
