DESCRIPTION

Unit

Technical Parameters

Screw Diameter

mm

60

65

Injection Capacity

cm3

641

753

Injection Weight

g

583

685

Injection Rate

g/s

235

275

Plasticizing Capacity

g/s

30

32.5

Injection Pressure

Mpa

142

121

Screw Speed

Rpm

0-180

Clamp Tonnage

KN

2400

Moulding Board Movement

mm

480

SpaceBetweenTie-bars(W*H)

mm

520*520

Max Mould Thickness

mm

560

Min Mould Thickness

mm

200

Ejector Distance

mm

102

Ejector Tonnage

KN

62

Max Pump Pressure

Mpa

16

Pump Motor Power

KW

22

Hester Power

KW

14.2

Machine Dimensions(L*W*H)

m*m*m

5.5*1. 63*2.2

Machine Weight

T

7.1
