DESCRIPTION

Unit

Technical Parameters

Screw Diameter

mm

35

38

Injection Capacity

cm3

158

187

Injection Weight

g

144

170

Injection Rate

g/s

82

96

Plasticizing Capacity

g/s

12

13.5

Injection Pressure

Mpa

169

144

Screw Speed

Rpm

0-220

Clamp Tonnage

KN

900

MouldingBoardMovement

mm

290

SpaceBetweenTie-bars(W*H)

mm

355*315

Max Mould Thickness

mm

370

Min Mould Thickness

mm

125

Ejector Distance

mm

64

Ejector Tonnage

KN

27

Max Pump Pressure

Mpa

16

Pump Motor Power

KW

11

Hester Power

KW

5.2

Machine Dimensions(L*W*H)

m*m*m

3.6*1.35*1.75

Machine Weight

T

2.7
